Chiptuning Seat
Up to 30% more power for your Seat
Our Seat catalog covers 187 engines (models: 11, generations: 19). For 66% of the engines there are the GAN GT (up to 30% more power) and GAN GTL (up to 25%) tuning boxes; for the rest, the GAN GA and GAN GA+ (up to 12%). Each engine’s figures are on its own page.
Seat plug-in remap: no changes to the ECU software
The tuning box sits between the sensors and the engine control unit (ECU) and adjusts their signals – unlike a flash remap, which rewrites the ECU. Your manufacturer’s warranty is preserved: the ECU software is never changed, and the box can be removed at any time.
- Bluetoothchange modes from your phone
- 18 mapsfine-tuning for your engine
- 15 minutesfitted to the factory connectors
- IP67water and dust protection
- up to +30%more power with the GAN GT
Turbo engines pick up +15 to +77 hp, depending on the engine.
- up to +12%for naturally aspirated engines with the GAN GA+
GAN GA and GAN GA+ tuning boxes for 27 naturally aspirated engines from Seat; see the catalog for each engine’s figure.
- GAN APPpower control via smartphone
SPORT, DYNAMIC, ECO and STOCK modes in the GAN app.
- 50 daystest drive
Feel the difference or get your money back, excluding delivery costs.
Choose your Seat model
Each model lists its generations: one click takes you to a generation, two to an engine.
The biggest Seat gains
The six engines with the biggest gains in our catalogue. These are not typical figures but the top of the range.
| Model · generation | Engine | Fuel | STOCK | With GAN | Gain | Tuning boxes and prices |
|---|---|---|---|---|---|---|
| Leon Leon (1P) 2005-12 | 2.0 TFSI Cupra 310 Limited Edition | Diesel | 310 hp / 425 Nm | 387 hp / 534 Nm | +77 hp | GTL from 279 EUR GT from 459 EUR |
| Leon Leon (1P) 2005-12 | 2.0 TFSI Copa Edition | Petrol | 286 hp / 360 Nm | 359 hp / 457 Nm | +73 hp | GTL from 249 EUR GT from 399 EUR |
| Leon Leon (5F) 2012-> | 2.0 TSI Cupra | Petrol | 300 hp / 380 Nm | 373 hp / 500 Nm | +73 hp | GTL from 279 EUR GT from 459 EUR |
| Leon Leon (5F) 2012-> | 2.0 TSI Cupra 265 | Petrol | 265 hp / 350 Nm | 335 hp / 445 Nm | +70 hp | GTL from 249 EUR GT from 399 EUR |
| Leon Leon (1P) 2005-12 | 2.0 TFSI Cupra | Petrol | 241 hp / 300 Nm | 306 hp / 385 Nm | +65 hp | GTL from 249 EUR GT from 399 EUR |
| Altea Altea | 2.0 TFSI | Petrol | 211 hp / 280 Nm | 275 hp / 381 Nm | +64 hp | GTL from 249 EUR GT from 399 EUR |
Seat remapping: questions
1.9 or 2.0 TDI in a Leon or Ibiza: pump injector or common rail?
The catalogue lists pump-injector (PD) and common-rail (CR) versions separately, even when the power output is the same. In the Leon II the PD engines have codes such as BKD and the common-rail ones codes such as CFHC, so check your engine code before you choose. A UK Leon Mk3 2.0 TDI was listed at 150 hp, and the catalogue has a 2.0 TDI 150 hp row for the Leon III.
What does the GAN GT add to the 1.4 TSI and other SEAT turbo petrols?
In the catalogue the Ibiza 1.4 TSI goes from 150 hp and 240 Nm to 195 hp and 315 Nm with the GAN GT. Each of the 1.0, 1.2 and 1.4 TSI has its own rows, as do the Ibiza 1.4 TSI FR and Cupra. These are the stated gains for the engine type, not a dyno reading from your own car.
What can a SEAT 1.4 MPI, 1.6 or 2.0 FSI gain with the GAN GA+?
All three are naturally aspirated petrols, so they suit the GAN GA+, rated at up to 12% more power.
Tuning box or remap for a SEAT TSI or TDI?
A remap rewrites the factory software, whereas the GAN tuning box works between the engine sensors and the ECU and adjusts their signals. The factory software, checksums and flash counter stay as they were, and the engine keeps its factory protections. Your manufacturer's warranty is preserved: the ECU software is never changed and the box can come off at any time.
Do I need to tell my insurer about a GAN tuning box?
Tell them. A tuning box raises the output, and in Britain that is a declarable modification like any other performance change. Policies differ, so a quick call to your insurer before fitting is the safe route; the figures they will ask for are the stock and GAN outputs on your engine's page.
Will a tuning box affect my Seat warranty?
No. The box does not change the ECU software and can be removed at any time, so your manufacturer’s warranty is preserved. On top of that, we give an engine warranty: 2 years with the GAN GT, 1 year with the GAN GTL.
Tuning box or remap: which should I choose?
A flash remap permanently rewrites the maps in the ECU and leaves a trace in the flash counter. The GAN tuning box adjusts the sensor signals instead: the ECU stays in factory condition, and you can return the car to stock in about a minute. A flash remap can be the better choice if the engine has upgraded hardware, or if the car is out of warranty and you accept the risks.
Seat chip tuning: what to know about the engines
SEAT remap or tuning box: Volkswagen engines under a Spanish badge
A SEAT tuning box is really a Volkswagen Group question: SEAT has belonged to the group since 1986 and shares its engines with Volkswagen, Audi and Škoda. The same engine families power the Golf, Octavia and A3 of those years: the Leon III runs the EA211 (1.0 to 1.5 TSI), the EA888 (1.8 and 2.0 TSI) and the EA288 (1.6 and 2.0 TDI). UK buyers call the third-generation Leon the Mk3.
SEAT trades under two names, SEAT and Cupra, and Cupra has been a brand in its own right since 2018. Until 2018 Cupra was simply the top trim, as in the Leon Cupra and the Cupra R. The Leon and the Ibiza are SEAT's two core models.
What the letters in SEAT engine names mean
TSI is a turbocharged direct-injection petrol, and every SEAT TSI from the 1.0 to the 2.0 has a turbo. The Ibiza 1.0 TSI is listed in Britain at 95 and 115 hp, and the catalogue has a row for each. TFSI is the older name for the same thing, as in the 2.0 TFSI of the Leon II FR, Cupra and Cupra R. FSI is direct injection without a turbo, so the 1.6 FSI and 2.0 FSI are naturally aspirated. MPI is a naturally aspirated petrol with multipoint injection, like the 1.0 MPI of the Ibiza V.
TDI is a turbodiesel, with pump injectors (PD) up to the end of the 2000s and common rail after that. On the 1.4 TSI at 150 hp and the 1.5 TSI, ACT switches off two of the cylinders. Ecomotive is a package for lower fuel use, as on the 1.6 TDI Ecomotive, not a separate engine. Most turbo engines suit the GAN GT (rated at up to 30% more power) and naturally aspirated ones the GAN GA+ (up to 12%); the catalogue decides which box applies to your engine.
Read moreShow less
Cupra, FR and the Ibiza Cupra
FR, for Formula Racing, is the sporty trim one step below Cupra. For a SEAT Leon Cupra remap the engine history runs from the 1.8T at 180 to 225 hp, via the 2.0 TFSI at 240 to 265 hp, to the 2.0 TSI at 265 to 300 hp. From 2009 to 2015 the Ibiza Cupra and FR used the 1.4 TSI Twincharger, which has both a supercharger and a turbo. In 2015 the Cupra switched to the 1.8 TSI at 192 hp.
Which SEAT models the catalogue covers
Beyond the Leon and Ibiza, the catalogue also covers the Altea, Toledo, Cordoba, Arosa, Alhambra, Exeo, Ateca, Arona and Tarraco. SEAT UK's current range lists the Ibiza, Arona and Leon; the Alhambra and Tarraco have been discontinued. The Inca, a van based on the Volkswagen Caddy, and the Málaga, a four-door Ibiza-based car of the 1980s, are not in the catalogue.
Which Seat models are in the catalog
The catalog covers 11 models from Seat. The most engines are listed for the Ibiza (56), Leon (45) and Toledo (21). The biggest gain among the models is on the Leon: up to +77 hp.
Naturally aspirated Seat engines
For 27 naturally aspirated engines from Seat, there is the GAN GA+: up to 12% more power and up to 15% lower fuel consumption in ECO mode, which means better MPG. You can fit it yourself, in most cases in under 15 minutes.
How to find your Seat engine
Pick your model from the list above, then the generation by model year and chassis code, then the engine by the power output in your registration document. The engine page shows the exact gain and the price of the box.
