Chiptuning Mercedes-Benz
Up to 30% more power for your Mercedes-Benz
Our Mercedes-Benz catalog covers 696 engines (models: 33, generations: 73). For 72% of the engines there are the GAN GT (up to 30% more power) and GAN GTL (up to 25%) tuning boxes; for the rest, the GAN GA and GAN GA+ (up to 12%). Each engine’s figures are on its own page.
Mercedes-Benz plug-in remap: no changes to the ECU software
The tuning box sits between the sensors and the engine control unit (ECU) and adjusts their signals – unlike a flash remap, which rewrites the ECU. Your manufacturer’s warranty is preserved: the ECU software is never changed, and the box can be removed at any time.
- Bluetoothchange modes from your phone
- 18 mapsfine-tuning for your engine
- 15 minutesfitted to the factory connectors
- IP67water and dust protection
- up to +30%more power with the GAN GT
Turbo engines pick up +15 to +122 hp, depending on the engine.
- up to +12%for naturally aspirated engines with the GAN GA+
GAN GA and GAN GA+ tuning boxes for 174 naturally aspirated engines from Mercedes-Benz; see the catalog for each engine’s figure.
- GAN APPpower control via smartphone
SPORT, DYNAMIC, ECO and STOCK modes in the GAN app.
- 50 daystest drive
Feel the difference or get your money back, excluding delivery costs.
Choose your Mercedes-Benz model
Each model lists its generations: one click takes you to a generation, two to an engine.
The biggest Mercedes-Benz gains
The six engines with the biggest gains in our catalogue. These are not typical figures but the top of the range.
| Model · generation | Engine | Fuel | STOCK | With GAN | Gain | Tuning boxes and prices |
|---|---|---|---|---|---|---|
| G G (W463) 2001-2018 | 500 | Petrol | 421 hp / 610 Nm | 543 hp / 773 Nm | +122 hp | GT from 519 EUR |
| AMG GT AMG GT | 63 AMG S | Petrol | 639 hp / 900 Nm | 748 hp / 1053 Nm | +109 hp | GTL from 379 EUR GT from 519 EUR |
| CLS CLS (C218) 2011-17 | 63 AMG S 5.5 | Petrol | 585 hp / 800 Nm | 689 hp / 955 Nm | +104 hp | GTL from 379 EUR GT from 519 EUR |
| E E (W212) 2009-16 | 63 AMG S 5.5 | Petrol | 585 hp / 800 Nm | 689 hp / 955 Nm | +104 hp | GTL from 379 EUR GT from 519 EUR |
| GLE GLE (W166) 2015-18 | 63 AMG S 5.5 | Petrol | 585 hp / 760 Nm | 689 hp / 915 Nm | +104 hp | GTL from 379 EUR GT from 519 EUR |
| GLS GLS (X166) 63 AMG | 5.5 | Petrol | 585 hp / 760 Nm | 689 hp / 915 Nm | +104 hp | GTL from 379 EUR GT from 519 EUR |
Mercedes-Benz remapping: questions
What should be checked on an OM 651 diesel before fitting a tuning box?
Start with the Delphi piezo injectors on the C 220 CDI, C 250 CDI, E 220 CDI and E 250 CDI: those from 2009 to 2011 could fail at around 50 thousand km and put the engine into limp mode. Separately, there was a 2014 recall of the chain tensioner. A tuning box does not repair or replace mechanical parts such as injectors or a timing chain, so have a garage look at both first.
M271 Kompressor or M271 CGI: what is the difference?
Built from 2002 to 2011, the M271 Kompressor relies on a mechanical supercharger. From 2009 the M271 EVO with CGI added a turbocharger and direct injection. Choose by engine and year: the catalogue pairs the Kompressor engines with the GAN GA+ and the CGI engines with the GAN GT. The C 200 Kompressor rises from 184 hp and 250 Nm to 206 hp and 280 Nm, the C 200 CGI from 184 hp and 270 Nm to 236 hp and 349 Nm.
Why does a C 250 CGI have a 1.8 and a C 300 a 2.0?
Since the W203 and W204 the number has been a power class, not a capacity: the W204 C 250 CGI has a 1.8-litre engine and the W205 C 300 a 2.0-litre one, and the C 250 CDI diesel is different again. That is why the catalogue asks for the engine code and year, not the number alone.
Mercedes remap or tuning box: what is left untouched?
A remap overwrites the factory software in the engine control unit, which makes it a different method from a tuning box. The GAN box works between the engine sensors and the ECU, adjusting their signals, so the factory software, checksums and flash counter remain untouched. The ECU software is never changed, and because the box can come off at any time your manufacturer's warranty is preserved.
Do I need to tell my insurer about a GAN tuning box?
Yes, declare it. British insurers treat extra power as a modification, so the safe course is to tell them before you fit the box. How they treat it varies from one insurer to another, so ask before you fit the box; the standard and tuned figures you will be asked for are on your engine's page.
Will a tuning box affect my Mercedes-Benz warranty?
No. The box does not change the ECU software and can be removed at any time, so your manufacturer’s warranty is preserved. On top of that, we give an engine warranty: 2 years with the GAN GT, 1 year with the GAN GTL.
Tuning box or remap: which should I choose?
A flash remap permanently rewrites the maps in the ECU and leaves a trace in the flash counter. The GAN tuning box adjusts the sensor signals instead: the ECU stays in factory condition, and you can return the car to stock in about a minute. A flash remap can be the better choice if the engine has upgraded hardware, or if the car is out of warranty and you accept the risks.
Mercedes-Benz chip tuning: what to know about the engines
Mercedes remap or tuning box: one diesel comes first
The OM 651 diesel is the place to start; it is the engine in the C 220 CDI, C 250 CDI, E 220 CDI and E 250 CDI. Its Delphi piezo injectors are the known weak point: those from 2009 to 2011 could fail at around 50 thousand km and leave the engine in limp mode. The timing chain and its tensioner come next, with a 2014 recall covering cars built between February and November of that year.
On the petrol side, look at the M271: it powers the C 200 CGI, the E 200 K, and the C 180 and C 200 Kompressor. The W204 C-Class headed its class in German registrations in 2010.
What the numbers and letters in a Mercedes badge mean
Since the W203 and W204, the number on the boot lid has been a power class rather than an engine size. Take the W204: a C 250 CGI has a 1.8-litre petrol, while the C 250 CDI diesel is a different size again. In the W205 a C 300 is a 2.0-litre and a C 400 a 3.0-litre. The letters carry meaning too: Kompressor is a mechanical supercharger, CGI is direct petrol injection, BlueEFFICIENCY is the W204's economy package, and 4MATIC is all-wheel drive. The M271 Kompressor was in production from 2002 to 2011, and the turbocharged, direct-injection M271 EVO with CGI followed from 2009.
In 2012 and 2013 the A, C and E received the 1.6 and 2.0-litre M270 and M274 turbo petrols, and the SLK followed in 2015. In the diesel range the V6 OM 642 arrived in 2005, and the OM 611/646 family was replaced by the OM 651 in 2008. CDI gave way to BlueTEC on diesels with SCR and AdBlue and then to a plain d, so a C 220 CDI becomes a C 220 BlueTEC and later a C 220 d. From 2014 a lower-case letter after the number marks the drive type: d for diesel, e for plug-in hybrid and h for hybrid, as in the C 350 e and C 300 h.
Read moreShow less
Which GAN box fits your Mercedes
Diesels and turbo engines mostly take the GAN GT in the catalogue, rated at up to 30% more power, while the naturally aspirated petrols take the GAN GA+, rated at up to 12%. So for a Mercedes remap the engine code decides: the W204 C 200 CGI, C 250 CGI and C 350 CDI all take the GAN GT. The GAN GT lifts the C 250 CGI BlueEFFICIENCY from 204 hp and 310 Nm to 261 hp and 397 Nm. Those are the stated gains for the engine type, not a dyno reading from your own car.
Supercharged Kompressor engines, the C 200 Kompressor for one, take the GAN GA+. The same goes for V6 and V8 petrol engines like the C 350 and the C 63 AMG. With hybrids such as the C 300 h and C 350 e, look up the engine in the catalogue before you assume a figure. Mercedes UK states a plug-in hybrid by its combined system output, so compare like with like.
Model renamings and body codes
Renamings to know: SLK to SLC in 2016 and ML to GLE in autumn 2015; in September 2012 the A-Class W169 was replaced by the W176. In May 2009 the CLK W209 Coupé was replaced by the E-Class Coupé C207, and the C-Class W205 gave way to the W206 in 2021. By code, the C-Class runs W202 to W205, the E-Class W210 to W213, the SLK R170 to R172, the M-Class W163, W164 and W166, and the A-Class W168, W169, W176 and W177. UK listings describe the body as Saloon, Estate, Coupé or SUV; the W-code is an enthusiast and parts reference rather than a model name.
Which Mercedes-Benz models are in the catalog
The catalog covers 33 models from Mercedes-Benz. The most engines are listed for the E (102), C (88) and S (55). The biggest gain among the models is on the G: up to +122 hp.
Naturally aspirated Mercedes-Benz engines
For 174 naturally aspirated engines from Mercedes-Benz, there is the GAN GA+: up to 12% more power and up to 15% lower fuel consumption in ECO mode, which means better MPG. You can fit it yourself, in most cases in under 15 minutes.
How to find your Mercedes-Benz engine
Pick your model from the list above, then the generation by model year and chassis code, then the engine by the power output in your registration document. The engine page shows the exact gain and the price of the box.
